Description

Glass Lid Vacuum Chamber with Pump

【ATTENTION】Please check the menu to select the right item.:)

【Features】Notice: You may need to apply a little pressure on the lid to get the gasket for better sealing

• ★ TEMPERED GLASS LID – Not only high-strength, impact resistant but also gives a better overview of the work. Specially designed for stabilizing wood and other experiments with volatile compounds. Ultra-sealed design to maintain high vacuum OVER 24h. WON’T CRACK!
• ★ HEAVY DUTY VACUUM PUMP – An integrated tank and all copper motor maximize the vacuum’s power. It delivers 4.5 CFM flow rate and -29.92inHg/5Pa/150microns vacuum with relatively low noise.
  Please note menu options that individual vacuum chamber do not include vacuum pump
• ★ SS304 CONTAINER – Strong and durable stainless steel container with chemical-resistant silicone gasket. Silicone gasket to be used over 10,000 times without deterioration.
• ★ LIQUID FILLED GAUGE – Resists vibrations and keeps the gauge accurate. Measuring range of vacuum gauge：0-30inHg, 5 Feet Reinforced Vacuum Hose Connect Directly To Vacuum Pump 1/4″ SAE.
• ★ APPLICATIONS – Stabilizing wood, degassing urethane, silicones, epoxies, stabilize, extracting essential oils from organic materials, etc

 【Vacuum Chamber】

• Internal Size for 1.5 Gallon Vacuum Chamber: 6″(H) x 7.8”(ID), Gauge mounted 1.5″ from the bottom of the chamber Please use a secondary container for your purpose
• Internal Size for 3 Gallon Vacuum Chamber: 9.8″(H) x 9.8”(ID)，Gauge mounted 6.6″ from the bottom of the chamber
• Internal Size for 5 Gallon Vacuum Chamber: 11.6″(H) x 11.6”(ID), Gauge mounted 8.8″ from the bottom of the chamber

【One Stage Vacuum Pump】

• Flow Rate: 4.5 CFM
• Ultimate Vacuum: Single Stage, -29.92inHg/5Pa/150microns
• Voltage: AC110V/60HZ, US PLUG，ONLY for the United States, If you are in Europe, please buy European standard vacuum pumps on other listings.
• Power: 1/3HP
• Inlet Valve: 1/4″ SAE
